[vc_row full_width=”stretch_row”][vc_column][vc_row_inner css=”.vc_custom_1587016150046{padding-top: 25px !important;padding-bottom: 25px !important;}”][vc_column_inner][vc_custom_heading text=”CLUTCH TROUBLESHOOTING” font_container=”tag:h1|text_align:center|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner css=”.vc_custom_1587016180830{padding-top: 25px !important;padding-bottom: 25px !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”1889″ img_size=”full” alignment=”center” css_animation=”rollIn”][/vc_column_inner][vc_column_inner width=”1/2″][vc_custom_heading text=”Loss of Drive” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal”][vc_custom_heading text=”ransmission has been hung on the shaft during installation. Angular misalignment of the transmission to engine.
-Install new clutch and support transmission during installation. Do not allow the transmission to hang on the clutch disc during installation. Check for missing bell housing dowel sleeves, worn pilot bushing/bearing or foreign matter between transmission and engine including wires, cables or brackets. The above problems will cause cracking in the segments, leading to separation of the damper and facing segments.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal”][vc_custom_heading text=”The clutch has been disengaged at speeds in excess of the maximum for the gear selected or the incorrect gear has been selected. This has caused the facings to burst. -Install new clutch and educate the driver.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal”][vc_custom_heading text=”Driver resting foot on the clutch pedal resulting in release system sticking.
-Install new clutch. Check all components of the release system, particularly self-adjusting release systems, and guide tubes. Check for leaking oil seals.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Noise and Vibration” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587027858813{padding-bottom: 10px !important;}”][vc_custom_heading text=”Noise when in Neutral Oil or grease has contaminated the disc pre-damper making it ineffective
-Install new clutch and sparingly use spline grease.
Noisy Clutch Broken location lug due to worn release fork and or no lubrication
-Replace any worn components and install new clutch. Apply high temp grease to the fork contact pads.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Chattering After Changing the Clutch” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587027945340{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Flywheel surface worn Replace or resurface flywheel and install a new clutch.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Grating Noise when Pulling Away” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587027993444{padding-bottom: 10px !important;}”][vc_custom_heading text=”-No lubrication on the clutch fork contact areas Clean and lubricate using the grease.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Noise During Release” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028020532{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Worn pilot bearing or bushing Replace pilot bearing or bushing” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Noise” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028058204{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Installation is missing the transmission to engine dowel sleeves or pilot bushing/bearing. This has created a concentric misalignment of the engine to the transmission. The torsion damper is destroyed, damper springs are broken, stop pins show contact from the hub flange and the hub pilot is worn. Carefully inspect for missing dowel sleeves and worn dowel sleeve holes in the bell housing. Replace pilot bushing/bearing and inspect the transmission to engine alignment.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Clatter on Engagement” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028155788{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Excessive amount or incorrect type of grease applied to input shaft Install new clutch and use spline grease.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Clutch Slippage” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028194084{padding-bottom: 10px !important;}”][vc_custom_heading text=”Slipping and Impossible to Change Gear
-Overheating due to excessive clutch slippage Install new clutch kit. Check all components of the release system, particularly self-adjusting release systems and guide tubes.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Check for leaking oil seals.” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028234531{padding-bottom: 10px !important;}”][vc_custom_heading text=”Slipping and Chattering Driver resting foot on the clutch pedal or incorrect clutch adjustment Do not use the clutch pedal as a footrest. Inspect for correct clutch adjustment.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Slipping” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028270235{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Clutch facing material is oil contaminated Replace leaking oil seals. Clean off oil and install new clutch.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Slipping” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028270235{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The self-adjusting mechanism has become jammed Replace or repair the self-adjusting mechanism or in the case of semiautomatic adjusters – reset.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Clutch Pedal” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028339771{padding-bottom: 10px !important;}”][vc_custom_heading text=”Noise While Depressing Clutch Pedal” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028359476{padding-bottom: 10px !important;}”][vc_custom_heading text=”-Seized release bearing due to excessive heat caused by incorrect bearing pre-load or loss of grease Install new clutch and check all components and adjustments of the release system i.e. cables, linkages, fork, ball studs, fork bushings and self-adjusting release systems.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Vibration Through the Clutch Pedal” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028394763{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The transmission shaft has struck and bent the diaphragm spring fingers during installation Install new clutch and carefully align and control the position of the transmission during installation.
Clutch Pedal Binding
-The release bearing guide tube is worn or the release arm/fork is bent or worn Install new clutch and guide tube. Inspect all release system components and repair or replace as needed.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Metallic Noise at Bottom of Pedal Travel” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028462091{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The release travel is excessive causing the diaphragm spring to contact the bearing carrier Install new clutch and ensure correct clutch adjustment.
Grating Noise and Stiff Pedal
-Insufficient lubrication of the clutch fork, particularly at the pivot point Clean and lubricate all components using a high temp grease. Replace the fork and ball stud if worn.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”Difficulty Changing Gears” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028616077{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The transmission was forced into position damaging the splines of the disc hub. Install new clutch and carefully control the position and alignment of the transmission during installation. Use a transmission jack and possibly install temporary guide pins to assist in aligning the transmission to the engine.
-The self-adjusting mechanism fails to lock due to worn ratchet and pawl. Repair self-adjusting release system. Replace ratchet and pawl.
The cover assembly has been dropped. Install new clutch. Inspect the drive straps for damage before installation.
-The cover has not been located on the flywheel dowel pins correctly. Install new clutch and ensure all flywheel dowel pins are in position and in good condition. Do not use air tools to tighten the bolts
-Release bearing travel is insufficient. Inspect release mechanism for full travel or lost motion due to worn parts. A stamped steel release arm can wear and break. Always remove and check arm and external pivots. Install new fork bushings and lubricate as required with high melting point grease.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner][vc_column_inner][vc_custom_heading text=”High Pedal Effort” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028515331{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The release bearing does not freely slide on the guide tube Clean and lubricate the guide tube to bearing contact area with high temp grease. If the guide tube is worn or scored, replace the guide tube.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][vc_row_inner css=”.vc_custom_1587028704538{margin-bottom: 50px !important;}”][vc_column_inner][vc_custom_heading text=”Metallic Noise at Bottom of Pedal Travel, Difficult Shifting” font_container=”tag:h3|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:600%20bold%20regular%3A600%3Anormal” css=”.vc_custom_1587028564204{padding-bottom: 10px !important;}”][vc_custom_heading text=”-The release travel is excessive causing the diaphragm spring to contact the clutch disc Install new clutch and ensure correct clutch adjustment.” font_container=”tag:p|text_align:left|color:%23000000″ google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row]
