Expert Installation & Field Note

Based on our shop experience specializing in heavy-duty brakes and clutches since 1985: When installing the CS3612475 slave cylinder, verify that the release fork and pivot points are lubricated and free of debris. Contamination is the primary cause of failure; always inspect the master cylinder and hydraulic lines for leaks or degraded fluid. We recommend gravity bleeding followed by a standard pressure bleed to ensure all air is purged from the 1-1/16-inch bore size chamber. Always use fresh, approved fluid to protect the internal seals.

⚠ CRITICAL: Verify Specifications

To ensure safety and proper clutch travel, verify that this slave cylinder’s 1-1/16-inch bore size and 7/16″ x 24 mounting configuration match your existing unit exactly. This component is designed for hydraulic clutch systems only; it is not compatible with mechanical linkage.
